1434 multichannel signal generator is a cost-effective and highly integrated microwave signal generator with a frequency range covering 9kHz to 20GHz/45GHz. It supports up to four channels, each with independently adjustable frequency and power, enabling multi-channel coherent signal output.
The series devices feature rich modulation capabilities, covering various modulation styles including frequency modulation, phase modulation, amplitude modulation, and pulse modulation. Achieving excellent performance in a compact space, it meets the testing needs of various fields such as communications, industrial electronics, and universities.
Main Features
- Frequency coverage 9kHz - 20GHz/45GHz
- Wide dynamic range power output
- High accuracy power output, measured value <0.5dB
- Excellent spectral purity, phase noise -123dBc/Hz (10GHz@10kHz, measured value)
- Standard configuration includes multiple modulation functions such as frequency modulation, phase modulation, amplitude modulation, and pulse modulation
- Supports cross-platform browser access control
- Supports USB power meter for testing, display, and power flatness calibration compensation
- Supports SCPI command recording, capable of generating programmable sample projects in Qt, C#, C++, etc.
- Supports USB and LAN interface programmable control
