87235 USB Average Power Sensor (8 kHz to 67 GHz)

The 87235 Series USB Average Power Sensor is a high precision, wide dynamic range average power measurement instrument based on the USB 2.0 interface, enabling accurate measurement of the average power of modulated signals.

Key Features

• Wide frequency range and Large measurement dynamic range
  • It features wide frequency coverage and a large dynamic range spanning 8 kHz to 67 GHz, and power measurements ranging from -70 dBm to +44 dBm
• Accurate measurement of multiple type signals
  • It enables the accurate measurement of the average power of modulated signals, making it ideal for power measurements in communications and other fields. Supported signal formats include continuous wave, pulse modulation and vector modulation, including 3G, 4 G and 5G
• Outstanding average power measurement accuracy
  • It delivers outstanding average power measurement accuracy. For instance, the 87235C achieves power measurement accuracy of 0.20 dB within the range of -40 dBm to +20 dBm
